Commercial Dried Lemon Kiwi Chips Heat Pump Food Dryer Fruit Dehydrator Machine
The heat pump food dryer uses steam and electric energy as a heat source, and operates the host through the reverse Carnot principle, so that the temperature in the drying room rises, and a large amount of hot air circulates in the box. The moisture exhaust port is discharged, thereby increasing the heat transfer effect and gradually reducing the moisture content of the material in the box.
THE HEAT PUMP DRYER FEATURES
1. Independent console, which can be controlled nearby or centralized in the control room for unified control.
2. The heat pump food dryer adopts an advanced hot air circulation system to make the temperature distribution of the studio uniform.
3. High-precision intelligent program temperature control instrument is used for temperature control, parameters are self-adjusted, and multi-segment program temperature control curves can be preset.
4. Intelligent temperature control instrument temperature control, sensitive and reliable control. The recorder records the temperature curve of the whole working process.
5. The over-temperature protection device can send out sound and light alarm signals and cut off the heating power to protect the safety of equipment and workpieces.
THE OVEN DRYER PARAMENTER
| Model | 5HF4 | 5HF6 | 5HF8 | 5HF10 | 5HF12 |
| Trolley | 4 | 6 | 8 | 10 | 12 |
| Tray Total | 60 trays | 90 trays | 120 trays | 150 trays | 180 trays |
| Tray Size(mm) | 1400*900 | 1400*900 | 1400*900 | 1400*900 | 1400*900 |
| Tray Capacity (Kg) | 12-20 | 12-20 | 12-20 | 12-20 | 12-20 |
| Tray Material | Plastic, Stainless Steel 304,304L,316 |
| Drying Capacity (kg/T) | 600-1000kg | 1000-2000kg | 1500-2500kg | 1800-3000kg | 2000-4000kg |
| Chamber Dimension (mm) | 5000*2300*2000 | 6600*2300*2000 | 8000*2300*2000 | 7000*3300*2000 | 8000*3300*2000 |
| Total Power (kw) | 26kw | 40kw | 48kw | 51.5kw | 57kw |
THE MATERIAL APPLICATION
THE COMPANY PROFILE
THE PATENT CERTIFICATE
THE SHIPMENT AND PACKGAGE
